Quality Ampoule Filling And Sealing Machine Manufacturer & Supplier In Canada
Ampoule Filling And Sealing Machine Details
Technogen Enterprise is a leading manufacturer, exporter, and supplier of high-quality Ampoule Filling and Sealing Machines designed for the pharmaceutical industry. With a strong reputation for reliability and innovation, our machines are built to meet the strictest CGMP standards, ensuring precise filling, efficient sealing, and maximum safety during production.
Available in 4-head, 6-head, and 8-head configurations, these machines are tailored to meet varying production requirements, from medium-scale to large-scale operations. Featuring advanced automation and robust construction, they deliver accuracy, hygiene, and efficiency in the handling of ampoules ranging from 1 ml to 20 ml.
The machine’s exclusive features, including the “No Ampoule – No Filling” system and pre & post gassing mechanism, make it the preferred choice for pharmaceutical manufacturers in Canada and across the globe.
Key Features of the Ampoule Filling and Sealing Machine
The Ampoule Filling and Sealing Machine is equipped with advanced features designed to improve productivity, minimize wastage, and ensure consistent results.
cGMP-compliant model built for pharmaceutical production environments.
Special induction gear motor and worm gearbox for perfect synchronization between filling, sealing, and transport mechanisms.
Machine frame fabricated from AISI 304 stainless steel for durability.
All contact parts made from AISI 316L stainless steel to maintain product safety.
Diving nozzles to prevent foaming and spillage during filling.
Filling capacity up to 20 ml with minimal changeover parts.
Integrated pre and post gassing system to maintain sterility.
Tray-based infeed and outfeed loading system for smooth operation.
Counting arrangement for efficient production monitoring.
Emergency stop button for operator safety.
Draw jaw sealing unit with pusher mechanism for reliable and consistent sealing.
Technical Specifications
| Model | TGAFS-60 | TGAFS-120 | TGAFS-180 |
|---|---|---|---|
| Name | Four Head Ampoule Filling & Sealing Machine | Six Head Ampoule Filling & Sealing Machine | Eight Head Ampoule Filling & Sealing Machine |
| Output | 60 Ampoules/min (depending on diameter) | 120 Ampoules/min (depending on diameter) | 160 Ampoules/min (depending on diameter) |
| Filling Accuracy | ±1% | ±1% | ±1% |
| Filling Range | 1 ml – 10 ml | 1 ml – 10 ml | 1 ml – 10 ml |
| No. of Filling Heads | 4 Heads | 6 Heads | 8 Heads |
| Power Requirement | 230 V, Single Phase, 50 Hz | 230 V, Single Phase, 50 Hz | 230 V, Single Phase, 50 Hz |
| Electrical Supply | 1 HP | 1.5 HP | 2 HP |
| Ampoule Size | 1 ml – 10 ml | 1 ml – 10 ml | 1 ml – 10 ml |
| Net Weight | 350 Kg | 450 Kg | 500 Kg |
| Dimensions (L x W x H) mm | 1250 × 1180 × 1250 | 1590 × 1180 × 1250 | 1850 × 1200 × 1300 |
Add-On Features
For enhanced customization and compliance, Technogen offers the following optional add-ons:
PLC – HMI interface for user-friendly operation.
Toughened glass or acrylic safety cabinet for operator safety and dust-free operation.
Exclusive Highlights
“No Ampoule – No Fill” mechanism prevents wastage of liquid and ensures process integrity.
Pre and Post Gassing System maintains product sterility, especially for sensitive pharmaceutical formulations.
Accurate dosing with ±1% filling accuracy.
Compact footprint makes it suitable for both standalone and integrated production lines.
Applicable Industries
The Ampoule Filling and Sealing Machine is primarily used in the pharmaceutical industry, where sterility, accuracy, and reliability are critical.
Applications include:
Sterile liquid injections
Vaccines
Ophthalmic solutions
Laboratory test samples
Specialized medical formulations
Benefits for Canadian Manufacturers
Technogen’s Ampoule Filling and Sealing Machine offers several key benefits to Canadian pharmaceutical manufacturers:
Regulatory Compliance – Designed to meet CGMP and international standards.
Scalable Production – Multiple head configurations to meet production demands.
Reduced Wastage – No ampoule, no filling system avoids product loss.
High Accuracy – ±1% filling precision ensures consistency across batches.
Sterile Environment – Pre and post gassing system enhances product quality.
Operator Safety – Equipped with safety cabinets and emergency stop functions.
Ease of Operation – User-friendly interface and simplified tray-based feeding.
Why Choose Technogen Enterprise?
Technogen Enterprise is recognized globally for its engineering excellence and customer-focused approach. By choosing our machines, you benefit from:
Robust design built to last with minimal maintenance.
Expert after-sales support and technical training.
Customization options to fit your specific production line requirements.
Proven track record of supplying to international pharmaceutical companies.
Cost-effective pricing without compromising on quality.
Conclusion
The Ampoule Filling and Sealing Machine by Technogen Enterprise is the ideal solution for pharmaceutical manufacturers in Canada seeking high-speed, accurate, and sterile filling systems. With head configurations ranging from 4 to 8, built-in safety mechanisms, and optional PLC-HMI integration, it offers a complete solution for small, medium, and large-scale production lines.
Whether you’re manufacturing injections, vaccines, or sterile liquids, this machine ensures precision, compliance, and efficiency at every stage of operation.
? Contact Technogen Enterprise today to request a detailed quotation, product demo, or customized solution for your pharmaceutical production needs.
