Premium Rinsing Filling Capping (RFC) Water Bottle Machine In Canada
Rinsing Filling Capping (RFC) Water Bottle Machine Details
Introduction: Bottling Made Easy in Canada
The demand for clean, safe, and efficiently packaged drinking water is higher than ever in Canada. Whether it’s mineral water, spring water, or purified bottled water, businesses need reliable machinery to meet production goals while ensuring quality. At Technogen Enterprise, we are proud to present the Rinsing Filling Capping (RFC) Water Bottle Machine—a fully integrated system designed to handle all three critical stages of bottling in one streamlined unit.
Our RFC water bottle machine is trusted across industries for its efficiency, precision, and durability. Specifically engineered to support Canadian bottled water companies, this equipment is ideal for both emerging businesses and large-scale enterprises. With production capacities ranging from 20 to 90 bottles per minute (BPM) for standard 1-liter bottles, the RFC series guarantees unmatched performance, helping you scale without compromise.
Why Choose an RFC Machine for Your Canadian Business?
Running a water bottling operation involves several complex processes—rinsing bottles, filling them with water, and securing them with caps. Traditionally, these steps required separate equipment and additional manpower, resulting in higher costs and inefficiencies.
The RFC Water Bottle Machine from Technogen solves this by integrating all three functions into a single synchronized system. This not only saves space and energy but also reduces operational costs, making it a smart choice for Canadian businesses looking to improve productivity.
Key benefits include:
Cost efficiency – Reduce manpower and eliminate multiple machines.
Space optimization – Compact design that fits well in Canadian facilities of all sizes.
Quality assurance – Advanced technology ensures every bottle is rinsed, filled, and capped to perfection.
Flexibility – Handles bottles from 100 ml to 1000 ml, accommodating different consumer preferences across Canada.
Scalability – Suitable for both small water plants and large-scale bottling companies.
User-Friendly Operation for Maximum Convenience
Technogen understands that not all operators are technicians. That’s why our RFC machines are designed with ease of use in mind.
Simple control panel for intuitive operation.
No Bottle – No Rinse – No Fill – No Cap system prevents wastage.
Air-blow conveyor for smooth bottle transfer.
Quick nozzle access for easy cleaning and maintenance.
With these features, Canadian businesses can focus on meeting demand without worrying about technical interruptions.
Salient Features of Technogen RFC Machine
Compact, space-saving design suitable for Canadian facilities.
Strong construction ensures vibration-free, stable operation.
Rotary neck holding technology secures bottles during operations.
Precision filling system with ±1% accuracy.
Pick & Place screw capping system for 100% reliable sealing.
Automatic cap feeder vibrator for continuous operation.
Speed indicator for real-time monitoring.
Compatible with low grammage preforms without distortion.
Integration-ready with shrink tunnels, labeling machines, and printers.
Magnetic hysteresis capping heads for efficient sealing.
Variable frequency drive (VFD) for adjustable speed.
Technical Specifications
Model | TGRFC-24 | TGRFC-30 | TGRFC-40 | TGRFC-60 | TGRFC-90 |
Direction | Left to Right | Left to Right | Left to Right | Left to Right | Left to Right |
Output | 24 BPM for 1000 ml bottle | 30 BPM for 1000 ml bottle | 40 BPM for 1000 ml bottle | 60 BPM for 1000 ml bottle | 90 BPM for 1000 ml bottle |
Filling Accuracy | ±1 % | ±1 % | ±1 % | ±1 % | ±1 % |
Filling Range | 100 ml to 1000 ml Water bottle | 100 ml to 1000 ml Water bottle | 100 ml to 1000 ml Water bottle | 100 ml to 1000 ml Water bottle | 100 ml to 1000 ml Water bottle |
No of Rinsing Head | 4 | 6 | 8 | 12 | 18 |
No of Filling Head | 4 | 6 | 8 | 12 | 18 |
No of Screw Capping Head | 2 | 3 | 4 | 6 | 6 |
Power requirement | 440V- 3 Phase 50Hz 4 Wire System | 440V- 3 Phase 50Hz 4 Wire System | 440V- 3 Phase 50Hz 4 Wire System | 440V- 3 Phase 50Hz 4 Wire System | 440V- 3 Phase 50Hz 4 Wire System |
Electrical supply | 2 HP | 2.5 HP | 3 HP | 3 HP | 4 HP |
Air Blowing Conveyor | 7 Feet | 8 Feet | 9 Feet | 9 Feet | 10 Feet |
Applications in Canada
Our RFC water bottle machines are ideal for:
Packaged drinking water plants
Mineral water bottling industries
Spring water suppliers
Beverage manufacturers expanding into bottled water markets
Whether you’re serving the urban Canadian retail market or supplying bottled water in remote communities, this machine is engineered to deliver consistent quality.
Why Canadian Businesses Trust Technogen
Global Experience, Local Focus – While headquartered in India, we provide solutions tailored for the Canadian market.
Energy Efficient – Designed to comply with energy-conscious operations, important in Canada’s eco-focused industries.
Durability in Harsh Conditions – Our machines are built to last, performing reliably even in varying Canadian climates.
After-Sales Support – Remote assistance, spare parts availability, and operator training ensure smooth long-term operations.
Future-Ready Technology
As the Canadian bottled water industry evolves, demand for automation, hygiene, and sustainability will only grow. Our RFC water bottle machine is future-ready:
Hygienic contact surfaces reduce contamination risk.
Efficient water usage supports sustainability goals.
Integration with labeling and coding systems prepares your business for Canadian retail compliance.
Conclusion: Invest in Reliability
The Technogen RFC Water Bottle Machine is more than just equipment—it’s an investment in productivity, consistency, and growth. For Canadian businesses seeking to compete in the bottled water market, it delivers the perfect balance of technology, reliability, and cost-efficiency.
Upgrade your bottling line today and experience the difference with Technogen.
