Automatic Rotary Bottle Screw Capping Machine In Canada
Automatic Rotary Bottle Screw Capping Machine Details
Automatic Rotary Bottle Screw Capping Machine
Technogen Enterprise, a trusted manufacturer, supplier, and exporter of packaging machinery, presents its Automatic Rotary Bottle Screw Capping Machine for Canadian industries.
Engineered in 4 head, 6 head, 8 head, and 12 head configurations, it delivers speeds from 60 to 200 bottles per minute, ensuring fast, precise, and hygienic sealing of glass, PET, HDPE, LDPE, and plastic bottles.
The machine uses a shut pick-up mechanism: bottles are separated by a feed worm, indexed through a star wheel, and capped by precision heads that pick caps directly from the chute. This makes it a robust, reliable, and low-maintenance choice for Canadian manufacturers in pharmaceuticals, beverages, cosmetics, and edible oil sectors.
Salient Features
CGMP-compliant modular design
All contact parts in SS 304 stainless steel for durability & hygiene
Compatible with glass, PET, HDPE, and plastic bottles
Single motor synchronization of conveyor, star wheel & turret
Slat stainless steel conveyor (optional modular/delrin belt available)
Jaw-type screw capping head with mechanical torque adjustment
No Bottle – No Cap system prevents wastage
Cap feeding flexibility: vibrator feeder, mechanical orientator, or elevator
Quick product changeover with minimal downtime
Low-maintenance construction
Inbuilt 6-digit production counter
Safety Features
No Bottle – No Cap automatic stop system
Emergency stop function for operator safety
Clutch at feed worm and star wheel prevents damage from bottle misfeeds
Outfeed jam detection halts machine to avoid breakdowns
Technical Specifications
| Parameter | 4 Head Model (TGSC-80) | 6 Head Model (TGSC-120) | 8 Head Model (TGSC-150) |
|---|---|---|---|
| Production Speed | 60–70 Bottles/Minute | 110–120 Bottles/Minute | 130–140 Bottles/Minute |
| Automation Grade | Automatic | Automatic | Automatic |
| Application | Screw capping for glass, plastic, PET bottles | Screw capping for glass, plastic, PET bottles | Screw capping for glass, plastic, PET bottles |
| Capping Type | Shut pick-up (single cam) | Shut pick-up (single cam) | Shut pick-up (single cam) |
| Transmission | Worm gearbox + Motor | Worm gearbox + Motor | Worm gearbox + Motor |
| Speed Control | Variable Frequency Drive (VFD) | Variable Frequency Drive (VFD) | Variable Frequency Drive (VFD) |
| Machine Motion | Rotary Continuous | Rotary Continuous | Rotary Continuous |
| Finish | Stainless Steel Matt Finish | Stainless Steel Matt Finish | Stainless Steel Matt Finish |
| Bottle Diameter Range | 22 – 80 mm | 22 – 80 mm | 22 – 80 mm |
| Bottle Height Range | 55 – 200 mm | 55 – 200 mm | 55 – 200 mm |
| Screw Cap Diameter | 22 – 52 mm (with change parts) | 22 – 52 mm (with change parts) | 22 – 52 mm (with change parts) |
| No. of Capping Heads | 4 | 6 | 8 |
| Capping Head Type | Jaw type with torque adjustment | Jaw type with torque adjustment | Jaw type with torque adjustment |
| Air Pressure Requirement | 2 KG/Cm² | 2 KG/Cm² | 2 KG/Cm² |
| Power Consumption | 1 HP Main + 0.25 HP Feeder | 1 HP Main + 0.25 HP Feeder | 2 HP Main + 0.50 HP Feeder |
| Cap Feeding Options | Vibrator, Orientator, Elevator | Vibrator, Orientator, Elevator | Vibrator, Orientator, Elevator |
| Electrical Connection | 440V, 3 Phase, 50 Hz | 440V, 3 Phase, 50 Hz | 440V, 3 Phase, 50 Hz |
| Control Panel | Bottom Pendant Type | Bottom Pendant Type | Bottom Pendant Type |
| Conveyor Height | Adjustable 800 – 850 mm | Adjustable 800 – 850 mm | Adjustable 800 – 850 mm |
| Dimensions (L × W × H) mm | 1830 × 850 × 1400 | 2130 × 875 × 1400 | 2130 × 915 × 1400 |
| Net Weight | 250 kg | 280 kg | 300 kg |
| Gross Weight | 450 kg | 480 kg | 500 kg |
Applications in Canada
Pharmaceuticals – screw caps for syrup, tablet & CRC bottles in Toronto & Montreal
Food & Beverages – sealing juices, milk, liquor & water bottles in Vancouver & Calgary
Cosmetics & Personal Care – shampoos, lotions, creams in Brampton & Mississauga
Edible Oils & Chemicals – secure capping for PET & HDPE bottles in Edmonton & Winnipeg
Distilleries & Breweries – fast capping solutions for spirits, beer & wine packaging
Final Thoughts
The Automatic Rotary Bottle Screw Capping Machine by Technogen Enterprise is a premium solution for Canadian industries looking for high-speed, reliable, and hygienic capping equipment.
With multi-head flexibility, shut pick-up precision, robust safety features, and low maintenance design, it integrates seamlessly into modern production lines.
Contact Technogen Enterprise today to get a customized quote and discover how this machine can optimize your Canadian packaging operations.
